- Place of Origin: Taian,China
- Brand Name: jinchihuayi
- Model Number: HDPE EF0.5
Performance feature:
Good physical performance, strong tearing resistance, strong deformation adaptability, puncture, ageing, ultraviolet, acid, alkali, corrosion and high and low temperature resistance,non-toxicity, very long operation life, using strict technologic formula, and adding enough materials such as antioxidant and light stabilizer. Good waterproof, drainage,anti-seepage and damp proof effects, complete width and thickness specifications,low cost and simple construction.
New Standard :
Common and High Density Polyethylene Geomembrane ( GH-1 ) | ||||||||||
Model No. 序号 | Item. 项目 | Specification 指标 | ||||||||
Thickness (mm) 厚度 | 0.30 | 0.50 | 0.75 | 1.00 | 1.25 | 1.50 | 2.00 | 2.50 | 3.00 | |
1 | Density ( g/cm3 ) 密度 | ≥0.940 | ||||||||
2 | Tensile yield strength (vertical and horizontal) ( N/mm ) 拉伸屈服强度(纵、横向) | ≥4 | ≥7 | ≥10 | ≥13 | ≥16 | ≥20 | ≥26 | ≥33 | ≥40 |
3 | Tensile Breaking Strength ( N/mm ) 拉伸断裂强度(纵、横向) | ≥6 | ≥10 | ≥15 | ≥20 | ≥25 | ≥30 | ≥40 | ≥50 | ≥60 |
4 | Tensile Elongation ( % ) 屈服伸长率(纵、横向) | ~ | ~ | ~ | ≥11 | |||||
5 | Elongation at Break ( % ) 断裂伸长率(纵、横向) | ≥600 | ||||||||
6 | Right angle tearing load 直角撕裂负荷(纵、横向) | ≥34 | ≥56 | ≥84 | ≥115 | ≥140 | ≥170 | ≥225 | ≥280 | ≥340 |
7 | Anti-puncture strength ( N ) 抗穿刺强度 | ≥72 | ≥120 | ≥180 | ≥240 | ≥300 | ≥360 | ≥480 | ≥600 | ≥720 |
8 | Carbon black content ( % ) 碳黑含量 | 2.0~3.0 | ||||||||
9 | Carbon black dispersity 碳黑分散性 |
Smooth and High Density Polyethylene Geomembrane ( GH-2S ) | ||||||||
Model No. 序号 | Item. 项目 | Specification 指标 | ||||||
Thickness (mm) 厚度 | 0.75 | 1.00 | 1.25 | 1.50 | 2.00 | 2.50 | 3.00 | |
1 | Density ( g/cm3 ) 密度 | ≥0.940 | ||||||
2 | Tensile yield strength (vertical and horizontal) ( N/mm ) 拉伸屈服强度(纵、横向) | ≥11 | ≥15 | ≥18 | ≥22 | ≥29 | ≥37 | ≥44 |
3 | Tensile Breaking Strength ( N/mm ) 拉伸断裂强度(纵、横向) | ≥20 | ≥27 | ≥33 | ≥40 | ≥53 | ≥67 | ≥80 |
4 | Tensile Elongation ( % ) 屈服伸长率(纵、横向) | ≥12 | ||||||
5 | Elongation at Break ( % ) 断裂伸长率(纵、横向) | ≥700 | ||||||
6 | Right angle tearing load 直角撕裂负荷(纵、横向) | ≥93 | ≥125 | ≥160 | ≥190 | ≥250 | ≥315 | ≥375 |
7 | Anti-puncture strength ( N ) 抗穿刺强度 | ≥240 | ≥320 | ≥400 | ≥480 | ≥640 | ≥800 | ≥960 |
8 | Tensile load stress cracking ( h ) 拉伸负荷应力开裂(切口恒载拉伸法) | ≥300 | ||||||
9 | Carbon black content ( % ) 碳黑含量 | 2.0~3.0 |
- Place of Origin: Taian,China
- Brand Name: jinchihuayi
- Model Number: HDPE EF0.5
Product Specification:
New Standard :
Common and High Density Polyethylene Geomembrane ( GH-1 ) | ||||||||||
Model No. 序号 | Item. 项目 | Specification 指标 | ||||||||
Thickness (mm) 厚度 | 0.30 | 0.50 | 0.75 | 1.00 | 1.25 | 1.50 | 2.00 | 2.50 | 3.00 | |
1 | Density ( g/cm3 ) 密度 | ≥0.940 | ||||||||
2 | Tensile yield strength (vertical and horizontal) ( N/mm ) 拉伸屈服强度(纵、横向) | ≥4 | ≥7 | ≥10 | ≥13 | ≥16 | ≥20 | ≥26 | ≥33 | ≥40 |
3 | Tensile Breaking Strength ( N/mm ) 拉伸断裂强度(纵、横向) | ≥6 | ≥10 | ≥15 | ≥20 | ≥25 | ≥30 | ≥40 | ≥50 | ≥60 |
4 | Tensile Elongation ( % ) 屈服伸长率(纵、横向) | ~ | ~ | ~ | ≥11 | |||||
5 | Elongation at Break ( % ) 断裂伸长率(纵、横向) | ≥600 | ||||||||
6 | Right angle tearing load 直角撕裂负荷(纵、横向) | ≥34 | ≥56 | ≥84 | ≥115 | ≥140 | ≥170 | ≥225 | ≥280 | ≥340 |
7 | Anti-puncture strength ( N ) 抗穿刺强度 | ≥72 | ≥120 | ≥180 | ≥240 | ≥300 | ≥360 | ≥480 | ≥600 | ≥720 |
8 | Carbon black content ( % ) 碳黑含量 | 2.0~3.0 | ||||||||
9 | Carbon black dispersity 碳黑分散性 |
Smooth and High Density Polyethylene Geomembrane ( GH-2S ) | ||||||||
Model No. 序号 | Item. 项目 | Specification 指标 | ||||||
Thickness (mm) 厚度 | 0.75 | 1.00 | 1.25 | 1.50 | 2.00 | 2.50 | 3.00 | |
1 | Density ( g/cm3 ) 密度 | ≥0.940 | ||||||
2 | Tensile yield strength (vertical and horizontal) ( N/mm ) 拉伸屈服强度(纵、横向) | ≥11 | ≥15 | ≥18 | ≥22 | ≥29 | ≥37 | ≥44 |
3 | Tensile Breaking Strength ( N/mm ) 拉伸断裂强度(纵、横向) | ≥20 | ≥27 | ≥33 | ≥40 | ≥53 | ≥67 | ≥80 |
4 | Tensile Elongation ( % ) 屈服伸长率(纵、横向) | ≥12 | ||||||
5 | Elongation at Break ( % ) 断裂伸长率(纵、横向) | ≥700 | ||||||
6 | Right angle tearing load 直角撕裂负荷(纵、横向) | ≥93 | ≥125 | ≥160 | ≥190 | ≥250 | ≥315 | ≥375 |
7 | Anti-puncture strength ( N ) 抗穿刺强度 | ≥240 | ≥320 | ≥400 | ≥480 | ≥640 | ≥800 | ≥960 |
8 | Tensile load stress cracking ( h ) 拉伸负荷应力开裂(切口恒载拉伸法) | ≥300 | ||||||
9 | Carbon black content ( % ) 碳黑含量 | 2.0~3.0 |
